PRESTONE T36 Series Powershift Transmission

150 to 240 kW (200 to 320 hp)

Yantai Prestone Power (YPP) T36 is the perfect replacement for Dana Spicer 36000 series powershift transmission. The T36 Series powershift transmission has been designed for heavy-duty applications, including rough terrain lift trucks; front end loaders; rough terrain cranes; and other mining, construction, and industrial machinery. The three-, four- and six-speed heavy-duty full powershift transmissions are available in a wide range of ratios with multiple configurations such as engine, midship or remote mounting.

APPLICATIONS-OF-T36-DANA-36000-FRONT-END-LOADER-FORKLIFT-HEAVY-DUTY-ROUGH-TERRAIN-MINING-CONSTRUCTION-INDUSTRIAL

Features and Benefits

  • 3-, 4-, and 6-speed full powershift transmissions
  • Short and long drops
  • Available in a wide range of ratios
  • Engine, midship or remote mounting
  • Flex plate drive



Options

  • Automatic lock-up
  • Automatic shift
  • Axle disconnect: front or rear, towing disconnect
  • Clutch modulation (3- and 4-speed only)
  • Clutch release: air or hydraulic
  • Emergency steering pump drive (only on long drop)
  • Provision for variable displacement pumps
  • Pump disconnect
  • Speedometer drive
  • Bi-directional PTO (4-speed only)
